Wagner TopFinish GM1030G, Conventional (AirSpray) Gravity Gun with excellent atomisation, the versatile TopFinish GM1030G AirSpray Gun delivers high-quality coating results, especially on smaller surfaces.
Wagner TopFinish GM1030G Gun
Product Description
Wagner TopFinish GM1030G Gun, Conventional Gravity AirSpray Gun with excellent atomisation, the versatile TopFinish GM1030G AirSpray Gun delivers high-quality coating results, especially on smaller surfaces. The large material and air passages of the components also support perfect atomisation and at the same time allow very fast working.
The optimised air channel ensures very low paint mist and saves material consumption. For process-reliable coating with a consistent material flow rate, the Wagner TopFinish GM1030G is equipped with a fixable needle stroke adjustment.
Features & Benefits
- Flexible Application Possibilities – The gravity cup gun is ideal for small-area coating applications and touch-up work, such as in the wood, metal or plastics industries. Suitable for all material types as all wetted parts are made of stainless steel. High flexibility due to a wide range of nozzle sizes and air caps. Suitable for Plastic coating, Metal coating, Wood coating & Adhesive bonding.
- High Efficiency – Transfer efficiency of up to 88%. Excellent atomisation quality and low paint mist thanks to optimised air duct and air distribution nozzle.
- Reliable Coating Process – Individual and precise material flow with fixable needle stroke adjustment. Large material and air passages of the components allow very fast working.
- Low Maintenance – Due to the two-part nozzle, it is sufficient to replace only the nozzle head instead of the complete nozzle, if necessary. Long-life needle packings and solvent-resistant polyethylene seals contribute to high availability.
- Easy Handling – Easy positioning of the air cap without loosening the screw ring. Individual adjustment of the spray jet width with just one rotary knob – from flat to round jet. Fatigue-free working thanks to ergonomic design and optimum weight distribution.
Product Variants
Technical Data
Further Information
Additional information
| Product Variants | Wagner GM1030G CONV (10 Hole) 1.0mm, Wagner GM1030G CONV (10 Hole) 1.2mm, Wagner GM1030G CONV (10 Hole) 1.5mm, Wagner GM1030G CONV (10 Hole) 1.8mm, Wagner GM1030G CONV (10 Hole) 2.0mm, Wagner GM1030G CONV (10 Hole) 2.2mm, Wagner GM1030G HVLP 1.2mm, Wagner GM1030G HVLP 1.3mm, Wagner GM1030G HVLP 1.4mm, Wagner GM1030G HVLP 1.5mm, Wagner GM1030G HVLP 1.8mm, Wagner GM1030G HVLP Plus 1.0mm, Wagner GM1030G HVLP Plus 1.2mm, Wagner GM1030G HVLP Plus 1.3mm, Wagner GM1030G HVLP Plus 1.4mm, Wagner GM1030G HVLP Plus 1.5mm, Wagner GM1030G HVLP Plus 1.8mm, Wagner GM1030G HVLP Plus 2.0mm, Wagner GM1030G HVLP Plus 2.2mm |
|---|
