Name: Wagner FFC Material Regulator
SKU: 34714
Availability: InStock

Wagner FFC Material Regulator

Yorkshire Spray Services Ltd - Wagner Double Diaphragm Pumps - Wagner FFC 14 0.5-8bar Pneum. Alu Part No. T0180.00A

Price range: £372.81 through £631.58 + VAT

Wagner FFC Material Regulator, pneumatically controlled Fine Flow Control. The low pressure FFC regulator has been designed for precise material control.


	NEXT working day delivery for orders placed before 12.00pm. Delivery on back ordered products approx. 4 – 7 days delivery

SKU: N/A Low Pressure Pump Spares, Material Pressure Regulators

Description Reviews (0)

Product Description

Wagner FFC Material Regulator, pneumatically controlled Fine Flow Control. The low pressure FFC regulator has been designed for precise material control. The Wagner FFC Material Regulator has a flow capacity up to 2.0ltr/min, along with highly sensitive adjustment for accurate flow regulation, with an adjustable pressure range up to 8 bar. Product resistant Stainless Steel version for Water and Solvent Based Lacquers, available in Stainless Steel or Aluminium. Supplied as standard on the Wagner Zip52 Finishing Pumps.

Product Variants

Description	Max. Inlet Pressure (bar)	Range (bar)	Material Outlet	Material Inlet	Control Air Connection	Body Material	Service Set	Diaphragm Set	Part No.
FFC 14/0,5-8bar pneum. Alu	14	0.5 – 8	G 1/4″ – F	G 1/4″ – F	G 1/8″ – F	Consistal	T6193.00	T9086.00	T0180.00A
FFC 14/0,5-8bar pneum. SSt	14	0.5 – 8	G 1/4″ – F	G 1/4″ – F	G 1/8″ – F	SSt	T6193.00	T9086.00	T0180.00AI
FFC 14/0,5-8bar pneum. SSt/Ceramic	14	0.5 – 8	G 1/4″ – F	G 1/4″ – F	G 1/8″ – F	SSt	T6193.00	T9086.00	T0180.00AIC
